Build 78 - April 19th 2014
This is an update which corrects the Bleed-over from Aux 1 to Aux 2 (you can send the output of Aux 1 directly to Aux 2).
Additionnally, some modifications:
- The Gain Modulation of each auxiliary effect is now a circuit that is placed just before the Aux Inserts. There is no more "pre" or "post" choice, it is always "pre".
- The Gain modulation can now be set by the user. Previously, it was always set to the maximum, but now, the user can change that.
- The gain modulation knobs act on both Left and Right modulation.
- Aux Gain Modulation allows, for example, to modulate the levels of audio that is sent to a delay or reverb, allowing to create rythmic or modulated effects, by sending audio to the effect only temporarily (for example, modulated by LFOs or step sequencers).
NB: the modulation of the Left and Right channels are still selected independantly, allowing to make L/R pan effects. However, the "Level" of the modulation ("m" knob = modulation amount), is the same for both left and right channels. Typically, gain modulation uses LFOs or step sequencers on one channel, and the "R" (reversed) version of that modulation on the other channel.
Other modifications: *some* labelling and tooltips were rewritten when it was really confusing.
This device is part of the LBH VIII Package. LBH-LE is fully functional with Xite-1.
THIS PACKAGE contains no dsp file, key, nor oscillators or filters.
It is an update that is available only to registered users of LBH VIII
Check with Sonic Core if you want to obtain a demo key for LBH VIII and its add-ons.
